OUTDOOR SPA M-3307

Function
1. Heating system
5. Circulating filtration system
2. illumination system
6. Air froth system
3. massage jet system
7. Computer control panel
4. Ozone disinfection system
Category:

Description

Specification
Rated Voltage: AC 220V / 110V
Bottom Lamp Horsepower: 3W
Rated Frequency: LF50HZ/ 60HZ
Product Size: 3000 x 2200 x 980 mm
Control Circuit Voltage: DC12V
Packing Size: 3100 X 2300 X 1080 mm
Water Pump Horsepower: 3*2HP
Volume: 7.7 Cubic Meter
Heater Horsepower: 3000W



Disposition
Water pump (3HP):1pcs
Water pump(2HP):2pcs
Water pump(0.5HP):2pcs
Total jets: 111pcs
Air pump(700W): 1pc
3 inch jets: 9pc
Paper element filter: 1pc
2.5 inch jets: 14pcs
USA Ozone-sterilization: 1pc
2 inch jets:69pcs
USA Heater(3KW): 1pc
Air jets: 19pcs
Control Panel:1pc
Bottom light(3W): 1pc
Pillow: 4 pcs
Water pipe & valve: 1batch
Plastic hem: 1set
Drain on skirt: 1pc
2 inch diversion:1pcs
Air diversion:5pcs
DVD:1pc
Small LED:20pcs
Big LED:1pc
Pop-up Speakers:4pcs
Fountain with light:2pcs
Insulation on the tub:1 set
Cover:1pc
2 Step ps ladder: 1set
